Valves and solenoid valves
replacement time approx. 5 week(s)
Item no:458-34
Description of the
5/2-way valve, G1/8 port, bistable - Mod. 458, Commercial code: 458-34, Standard and certifications: CE, Standard and certifications: +60, Min operating temperature [°C]: 0, Max IP protection w/ connector: N.a., Type of pneumatic connection: Gas threading, Pneumatic connection: G1/8, Max input pressure [bar]: 10, Oxygen service: No, Media: Air, Body material: Aluminium, Seal material: NBR, Kv value [m³/h]: -, Type of electrical connection: - Absent, Manual override: - Absent, Series: 4, Orifice [mm]: - Absent, Standard: - Absent, Flow rate (Qn) [l/min ANR]: 650, Valve function: 5/2, Actuation type: Pneumatically operated, Voltage: - Absent
